PTC weerstanden

0.3 Ohm PTC Thermistor | B59935-C120-A70

Epcos
B59935-C120-A70 | ***V8 | 29042013
UITLOPEND NOG 8 STUKS OP VOORRAAD
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Producent EPCOS
  • Type sensor PTC thermistor
  • Soort verzekering keramisch
  • Min. weerstand 300mΩ
  • Maximale spanning 30V
  • Schakelstroom 1.8A
  • Nominale stroom   mA
  • Werktemperatuur -40...125°C
  • Aansluitraster 5mm
  • Diameter 22mm
  • Nominale spanning 24V
  • Afmetingen aansluitingen Ø0.6x35mm
  • Elektrische levensduur 100 cycli
  • Dikte 3.5mm
  • Omschakeltijd 10s

0.45 Ohm PTC Thermistor | B59945-C120-A70

Epcos
B59945-C120-A70 | ***V3 | 29042013
UITLOPEND NOG 3 STUKS OP VOORRAAD
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Producent EPCOS
  • Type sensor PTC thermistor
  • Soort verzekering keramisch
  • Min. weerstand 300mΩ
  • Maximale spanning 30V
  • Schakelstroom 1.3A
  • Nominale stroom   mA
  • Werktemperatuur -40...125°C
  • Aansluitraster 5mm
  • Diameter 17.5mm
  • Nominale spanning 24V
  • Afmetingen aansluitingen Ø0.6x35mm
  • Elektrische levensduur 100 cycli
  • Dikte 3.5mm
  • Omschakeltijd 10s

0.8 Ohm PTC Thermistor | B59955C0120A070

Epcos
B59955C0120A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Producent EPCOS
  • Type sensor PTC thermistor
  • Soort verzekering keramisch
  • Min. weerstand 800mΩ
  • Maximale spanning 30V
  • Schakelstroom 1.7A
  • Nominale stroom 850mA
  • Werktemperatuur -40...125°C
  • Aansluitraster 5mm
  • Diameter 13.5mm
  • Nominale spanning 24V
  • Afmetingen aansluitingen Ø0.6x35mm
  • Elektrische levensduur 100 cycli
  • Dikte 3.5mm
  • Omschakeltijd 10s

1.2 Ohm PTC Thermistor | B59965C0120A070

Epcos
B59965C0120A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Producent EPCOS
  • Type sensor PTC thermistor
  • Soort verzekering keramisch
  • Min. weerstand 1.2Ω
  • Maximale spanning 30V
  • Schakelstroom 1.2A
  • Nominale stroom 600mA
  • Werktemperatuur -40...125°C
  • Aansluitraster 5mm
  • Diameter 11mm
  • Nominale spanning 24V
  • Afmetingen aansluitingen Ø0.6x35mm
  • Elektrische levensduur 100 cycli
  • Dikte 3.5mm
  • Omschakeltijd 10s

1.65 Ohm PTC Thermistor | B59930C0120A070

Epcos
B59930C0120A070 | 29042013
kg
    Levertijd:geen voorraad artikel levertijd 2-4 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 1.65 Ohm
  • Spanningswaarde max. 63V
  • Breedte 22mm
  • Lengte 25.5mm
  • Nominale stroom 700mA
  • Schijfdiameter 22mm
  • Opslagtemperatuur min .-25°C
  • Hoogte 3.5mm
  • Opslagtemperatuur max. 45°C

1.8 Ohm PTC Thermistor | B59975C0120A070

Epcos
B59975C0120A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Producent EPCOS
  • Type sensor PTC thermistor
  • Soort verzekering keramisch
  • Min. weerstand 1.8Ω
  • Maximale spanning 30V
  • Schakelstroom 0.9A
  • Nominale stroom 450mA
  • Werktemperatuur -40...125°C
  • Aansluitraster 5mm
  • Diameter 12.5mm
  • Nominale spanning 24V
  • Afmetingen aansluitingen Ø0.6x35mm
  • Elektrische levensduur 100 cycli
  • Dikte 3.5mm
  • Omschakeltijd 10s

3.7 Ohm PTC Thermistor | B59960C0120A070

Epcos
B59960C0120A070 | ***V8 | 29042013
UITLOPEND NOG 8 STUKS OP VOORRAAD
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 3.7 Ohm
  • Spanningswaarde max. 63V
  • Breedte 3.5mm
  • Nominale stroom 25mA
  • Schijfdiameter 11mm
  • Opslagtemperatuur min. -25°C
  • Hoogte 14.5mm
  • Opslagtemperatuur max. 45°C

5.6 Ohm PTC Thermistor | B59960C0080A070

Epcos
B59960C0080A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 5.6 Ohm
  • Spanningswaarde max. 63V
  • Breedte 11mm
  • Lengte 14.5mm
  • Nominale stroom 130mA
  • Schijfdiameter 11mm
  • Opslagtemperatuur min .-25°C
  • Hoogte 3.5mm
  • Opslagtemperatuur max. 45°C

6 Ohm PTC Thermistor 230V | B59840-C120-A70

Epcos
B59840-C120-A70 | ***V1 | 29042013
UITLOPEND NOG 1 STUKS OP VOORRAAD
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 6 Ohm
  • Spanningswaarde max. 230V
  • Breedte 17.5mm
  • Nominale stroom 330mA
  • Schijfdiameter 17.5mm
  • Opslagtemperatuur min. -25°C
  • Hoogte 21mm
  • Opslagtemperatuur max. 45°C

9.4 Ohm PTC Thermistor | B59970C0080A070

Epcos
B59970C0080A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 9.4 Ohm
  • Spanningswaarde max. 63V
  • Breedte 9mm
  • Lengte   mm
  • Nominale stroom 90mA
  • Schijfdiameter 9mm
  • Opslagtemperatuur min .-25°C
  • Hoogte 12.5mm
  • Opslagtemperatuur max. 45°C

55 Ohm PTC Thermistor | B59990C0120A070

Epcos
B59990C0120A070 | 29042013
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 55 Ohm
  • Spanningswaarde max. 63V
  • Breedte 4mm
  • Lengte   mm
  • Nominale stroom 50mA
  • Schijfdiameter 4mm
  • Opslagtemperatuur min .-25°C
  • Hoogte 7.5mm
  • Opslagtemperatuur max. 45°C

150 Ohm PTC Thermistor 230V | B59890-C120-A70

Epcos
B59890-C120-A70 | ***V4 | 29042013
UITLOPEND NOG 4 STUKS OP VOORRAAD
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Type thermistor PTC
  • Weerstand bij 25 °C 150 Ohm
  • Spanningswaarde max. 230V
  • Breedte 4mm
  • Nominale stroom 30mA
  • Schijfdiameter 4mm
  • Opslagtemperatuur min. -25°C
  • Hoogte 7.5mm
  • Opslagtemperatuur max. 45°C
