92x92mm | 230Vac Ventilatoren

230Vac Sunon ventilator kogellager 92x92x25mm | SF23092A2092HBT

Sunon
SF23092A2092HBT | ###V1 | LFT 23092KU | 24012023
kg
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel

Productspecificaties

  • Ventilatortype AC
  • Soort ventilator axiaal
  • Ventilatorgrootte 92x92x25mm
  • Vermogensverbruik 14.5W
  • Nominale stroom 70mA
  • Efficiëntie ventilator 51m3/h (±7%)
  • Geluidsniveau 37dBA
  • Soort lager kogel
  • Rotatiesnelheid 2350omw./min
  • Stroom- en vermogensafnametolerantie ±15%
  • Frequentie 50Hz
  • Min. resistantie van de isolatie 500MΩ
  • Materiaal waaier thermoplast
  • Materiaal behuizing aluminium
  • Isolatieklasse B
  • Uitgang connectoren 2,8x0,3mm
  • Werktemperatuur -10...70°C
  • Ontvlambaarheidsklasse UL94V-0
  • Statische druk 3.3mm H2O
  • Massa 280g

230Vac Sunon ventilator glijlager 92x92x25mm | SF23092A2092HST

Sunon
SF23092A2092HST | LFT 23092 | 24012023
kg
    Levertijd:geen voorraad artikel levertijd 2-4 werkdagen
Bestel

Productspecificaties

  • Ventilatortype AC
  • Soort ventilator axiaal
  • Ventilatorgrootte 92x92x25mm
  • Vermogensverbruik 14.5W
  • Nominale stroom 70mA
  • Efficiëntie ventilator 49m3/h (±7%)
  • Geluidsniveau 36dBA
  • Soort lager glij
  • Rotatiesnelheid 2250omw./min
  • Stroom- en vermogensafnametolerantie ±15%
  • Frequentie 50Hz
  • Min. resistantie van de isolatie 500MΩ
  • Materiaal waaier thermoplast
  • Materiaal behuizing aluminium
  • Isolatieklasse B
  • Uitgang connectoren 2,8x0,3mm
  • Werktemperatuur -10...70°C
  • Ontvlambaarheidsklasse UL94V-0
  • Statische druk 3.05mm H2O
  • Massa 280g
