120uF Elektrolytische condensatoren radiaal

120uF 16Vdc Elektrolytische condensator Low impedance | EEUFM1C121

Panasonic
EEUFM1C121 19122016
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel
  • Type: Aluminium Elektrolytische condensator
  • Low Impedance Low ESR
  • Constructie: Radiaal
  • Capaciteit: 120 µF
  • Nominale voltage 16 Vdc
  • Tolerantie: in capaciteit ±20%
  • Gebruiksduur: 2000h
  • Equivalent series resistance: 0.013 Ohm
  • Max. ripple current: 455mA
  • Temperatuurbereik: -40...+105 °C
  • Diameter: behuizing 6.3 mm
  • Lengte: 11.2 mm
  • Pitch: 2.5mm

120uF 25Vdc 85gr Elektrolytische condensator | 860010473008

Würth Elektronik
860010473008 19122016
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel
  • Type: Aluminium Elektrolytische condensator
  • Constructie: Radiaal
  • Capaciteit: 120 µF
  • Nominale voltage 25 Vdc
  • Tolerantie: in capaciteit ±20%
  • Gebruiksduur: 2000h
  • Equivalent series resistance: -- Ohm
  • Max. ripple current: --
  • Temperatuurbereik: -40...+85 °C
  • Diameter: behuizing 6.3 mm
  • Lengte: 11 mm
  • Pitch: 2.5 mm
