10.000uF Elektrolytische condensatoren radiaal

10.000uF 25Vdc Elektrolytische condensator | EEUHD1E103

Panasonic
EEUHD1E103 | 18012020
kg
    Levertijd:geen voorraad artikel levertijd 2-4 werkdagen
Bestel
  • Type: Aluminium Elektrolytische condensator
  • Constructie: Radiaal
  • Capaciteit: 10.000 µF, 10 mF
  • Nominale voltage 25 Vdc
  • Tolerantie: in capaciteit ±20%
  • Gebruiksduur: 2000h
  • Equivalent series resistance:
  • Max. ripple current, rimpel stroom:  2.2A
  • Leakage current, Lekstroom: 2.5mA
  • Temperatuurbereik: -55...+105 °C
  • Diameter: behuizing 18 mm
  • Lengte: 35.5 mm
  • Pitch: 7.5 mm

10.000uF 63Vdc Elektrolytische condensator | HL1J109M35050HA

Samwha
HL1J109M35050HA | mag/k | 24012024
    Levertijd:voorraad artikel 1-2 werkdagen
Bestel
  • Type: Aluminium Elektrolytische condensator
  • Constructie: Radiaal
  • Capaciteit: 10.000 µF
  • Nominale voltage 63 Vdc
  • Tolerantie: in capaciteit ±20%
  • Gebruiksduur: 5000h
  • Equivalent series resistance:
  • Max. ripple current:
  • Temperatuurbereik: -55...+105 °C
  • Diameter: behuizing 35 mm
  • Lengte: 50 mm
  • Pitch: 10 mm
